Hi Fam
I am pleased to introduce B4XDaisyAvatar, a versatile image component part of the B4X Daisy UI Kit series.
Inspired by the DaisyUI avatar utility, this component simplifies the creation of user profile pictures. It handles complex shape masking, status indicators (online/offline), and border rings automatically, drawing directly to a native canvas for high performance.
The "Glue": B4XDaisyVariants B4XDaisyAvatar is heavily powered by B4XDaisyVariants. The variants module calculates the complex geometry for shapes like Squircles and Hexagons and resolves abstract size tokens (e.g., "12" or "20") into native dip values.
Key Features
• Shape Masks: Supports over 20 built-in shapes including circle, squircle, hexagon, heart, star, and decagon.
• Status Indicators: Built-in "Online" (green dot) and "Offline" modes. The component automatically draws the status dot and a contrasting ring border around the avatar.
• Smart Cropping: Implements "Object-Fit: Cover" logic to ensure images fill the shape without distortion.
• Theme Aware: Can derive ring and status colors from your app's semantic palette (Primary, Secondary, Accent, etc.).
🛠 Dependencies
1. B4XDaisyVariants.bas (Static Code Module) - Included in the attachment
1. Designer Configuration: Add B4XDaisyAvatar to your layout.
• Mask: squircle
• Width/Height: 16 (Tailwind size token)
• ShowOnline: True
Designer Properties
• Image: Path to the image file (Assets or full path).
• Mask: The shape of the avatar (circle, square, squircle, hexagon, heart, etc.).
• Status: Sets the initial state (none, online, offline).
• ShowOnline: Toggles the visibility of the status dot.
• RingWidth: Width of the border ring (useful for separating the avatar from the background).
• Shadow: Apply a drop shadow depth (xs to 2xl).
Related Content
I am pleased to introduce B4XDaisyAvatar, a versatile image component part of the B4X Daisy UI Kit series.
Inspired by the DaisyUI avatar utility, this component simplifies the creation of user profile pictures. It handles complex shape masking, status indicators (online/offline), and border rings automatically, drawing directly to a native canvas for high performance.
The "Glue": B4XDaisyVariants B4XDaisyAvatar is heavily powered by B4XDaisyVariants. The variants module calculates the complex geometry for shapes like Squircles and Hexagons and resolves abstract size tokens (e.g., "12" or "20") into native dip values.
Key Features• Shape Masks: Supports over 20 built-in shapes including circle, squircle, hexagon, heart, star, and decagon.
• Status Indicators: Built-in "Online" (green dot) and "Offline" modes. The component automatically draws the status dot and a contrasting ring border around the avatar.
• Smart Cropping: Implements "Object-Fit: Cover" logic to ensure images fill the shape without distortion.
• Theme Aware: Can derive ring and status colors from your app's semantic palette (Primary, Secondary, Accent, etc.).
🛠 Dependencies
1. B4XDaisyVariants.bas (Static Code Module) - Included in the attachment
1. Designer Configuration: Add B4XDaisyAvatar to your layout.
• Mask: squircle
• Width/Height: 16 (Tailwind size token)
• ShowOnline: True
B4X:
Sub Globals
Private Avatar1 As B4XDaisyAvatar
Private Avatar2 As B4XDaisyAvatar
End Sub
Sub Activity_Create(FirstTime As Boolean)
Activity.LoadLayout("MainLayout")
' Set image from assets
Avatar1.SetAvatar("user_profile.jpg")
' Change status to Online (shows green dot + ring)
Avatar1.SetStatus("online")
' Dynamic configuration for a second avatar
Avatar2.SetAvatar("colleague.png")
Avatar2.SetAvatarMask("hexagon")
Avatar2.SetRingColor(xui.Color_Blue)
Avatar2.SetRingWidth(3dip)
End Sub
' Handle Clicks
Sub Avatar1_AvatarClick(Payload As Object)
Log("User clicked avatar!")
End Sub• Image: Path to the image file (Assets or full path).
• Mask: The shape of the avatar (circle, square, squircle, hexagon, heart, etc.).
• Status: Sets the initial state (none, online, offline).
• ShowOnline: Toggles the visibility of the status dot.
• RingWidth: Width of the border ring (useful for separating the avatar from the background).
• Shadow: Apply a drop shadow depth (xs to 2xl).
