I am guiding myself in this example https://www.b4x.com/android/forum/t...t-engine-bbcode-parser-rich-text-view.106207/ I want to add a radiobutton but i have problems doing it.
according to the error I try to initialize it but I have not succeeded, below the code
error:
Application_Start
Error occurred on line: 46 (B4XMainPage)
Object was not initialized (UIView)
Stack Trace: (
CoreFoundation 5198FB57-5645-3B34-A49F-F32B52256CF3 + 627356
libobjc.A.dylib objc_exception_throw + 60
CoreFoundation 5198FB57-5645-3B34-A49F-F32B52256CF3 + 983952
B4i Example -[B4IObjectWrapper object] + 116
B4i Example -[B4XViewWrapper SetLayoutAnimated:::::] + 60
B4i Example -[b4i_b4xmainpage _b4xpage_created::] + 1884
CoreFoundation 5198FB57-5645-3B34-A49F-F32B52256CF3 + 138020
CoreFoundation 5198FB57-5645-3B34-A49F-F32B52256CF3 + 259600
B4i Example +[B4I runDynamicMethod:method:throwErrorIfMissing:args:] + 1300
B4i Example -[B4ICommon CallSubDebug4::::] + 860
B4i Example -[B4ICommon CallSubDebug2::::] + 284
B4i Example -[b4i_b4xpagesmanager _createpageifneeded::] + 984
B4i Example -[b4i_b4xpagesmanager _showpage::] + 692
B4i Example -[b4i_b4xpagesmanager _addpage:::] + 1216
B4i Example -[b4i_b4xpagesmanager _addpageandcreate:::] + 532
B4i Example -[b4i_b4xpagesmanager _initialize:::] + 1592
B4i Example -[b4i_main _application_start:] + 592
CoreFoundation 5198FB57-5645-3B34-A49F-F32B52256CF3 + 138020
CoreFoundation 5198FB57-5645-3B34-A49F-F32B52256CF3 + 259600
B4i Example +[B4I runDynamicMethod:method:throwErrorIfMissing:args:] + 1300
B4i Example -[B4IShell runMethod:] + 448
B4i Example -[B4IShell raiseEventImpl:method:args::] + 2172
B4i Example -[B4IShellBI raiseEvent:event:params:] + 1580
B4i Example __33-[B4I raiseUIEvent:event:params:]_block_invoke + 52
libdispatch.dylib 355ACCF4-3917-3730-BC55-EF7003887ABE + 7788
libdispatch.dylib 355ACCF4-3917-3730-BC55-EF7003887ABE + 14896
libdispatch.dylib 355ACCF4-3917-3730-BC55-EF7003887ABE + 73544
libdispatch.dylib _dispatch_main_queue_callback_4CF + 44
CoreFoundation 5198FB57-5645-3B34-A49F-F32B52256CF3 + 333824
CoreFoundation 5198FB57-5645-3B34-A49F-F32B52256CF3 + 46852
CoreFoundation CFRunLoopRunSpecific + 600
GraphicsServices GSEventRunModal + 164
UIKitCore 3ED35565-456D-33CB-B554-6C567FA81585 + 5326408
UIKitCore UIApplicationMain + 364
B4i Example main + 104
dyld start + 520
)
Application_Activeaccording to the error I try to initialize it but I have not succeeded, below the code
Code:
#Region Shared Files
#CustomBuildAction: folders ready, %WINDIR%\System32\Robocopy.exe,"..\..\Shared Files" "..\Files"
'Ctrl + click to sync files: ide://run?file=%WINDIR%\System32\Robocopy.exe&args=..\..\Shared+Files&args=..\Files&FilesSync=True
#End Region
'Ctrl + click to export as zip: ide://run?File=%B4X%\Zipper.jar&Args=Project.zip
Sub Class_Globals
Private Root As B4XView
Private xui As XUI
Private BBCodeView1 As BBCodeView
Private TextEngine As BCTextEngine
Private xui As XUI
End Sub
Public Sub Initialize
End Sub
'B4i - don't miss the inline OBJC code in the main module.
Private Sub B4XPage_Created (Root1 As B4XView)
Root = Root1
Root.LoadLayout("1")
TextEngine.Initialize(Root)
BBCodeView1.TextEngine = TextEngine
Dim btn As Button
Dim rbtn As B4XRadioButton
#if B4i
btn.Initialize("btn", btn.STYLE_SYSTEM)
#Else If B4J or B4A
btn.Initialize("btn")
#End If
rbtn.Initialize(Me,"rbtn")
Dim xbtn As B4XView = btn
Dim xrbtn As B4XView = rbtn.mBase
If xui.IsB4i Then
xbtn.SetColorAndBorder(xui.Color_Transparent, 1dip, xui.Color_Black, 2dip)
End If
xbtn.Text = "Click!"
xbtn.SetLayoutAnimated(0, 0, 0, 100dip, 40dip)
' xrbtn.Text="hola mundo"
' rbtn.SetLayoutAnimated(0, 0, 0, 100dip, 40dip)
xrbtn.SetLayoutAnimated(0, 0, 0, 100dip, 40dip)
Dim pnl As B4XView = xui.CreatePanel("")
pnl.SetLayoutAnimated(0, 0, 0, 200dip, 120dip)
BBCodeView1.Views.Put("btn", btn)
BBCodeView1.Views.Put("rbtn", rbtn)
BBCodeView1.Text = _
$"[Alignment=Center][TextSize=20][b][u]This is the title [FontAwesome=0xF034/] [FontAwesome=0xF035/][/u][/b][/TextSize][/Alignment]
Emoji made of multiple "characters": ?? and a flag: [TextSize=30][e=??/][/TextSize]
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Nunc fermentum elit vitae nisi faucibus, vitae lacinia turpis mattis.
Lets add a [Color=#ff0000][b]button:[/b][/color] [View=btn Vertical=10/] and more text here...
We can also add links, for example: [url]https://www.google.com[/url]. You can click on the link. The title will be updated.
Here is a nice logo: [img FileName="logo.png" width=50/]
We can also download an image here: [url="DonManfred's avatar"][img url="https://b4x-4c17.kxcdn.com/android/forum/data/avatars/l/42/42649.jpg?1432374732" width=60 height=60/][/url]
Note that you must explicitly set the dimensions of such images.
Colors:
[list]
[*][Color=#ff0000][b][u]Red[/u][/b][/Color]
[*][Color=#00ff00][b][u color=Magenta]Green[/u][/b][/Color]
[*][Color=#0000ff][b][u color=DarkGray Thickness=3]Blue[/u][/b][/Color]
[/list]
Items:
[list style=ordered]
[*]Item A
[*]Item B
[*]Item C
[/list]
${TableRow("[b]Column 1[/b]", "[b]Column 2[/b]", "[b]Column 3[/b]")}
${TableRow($"[img FileName="logo.png" width=30/]000"$, "100", "200")}
${TableRow($"[color=#ff0000][b]-232[/b][/color]"$, "AAA", "CCC")}
${TableRow($"[color=#ff0000][b]-232[/b][/color]"$, "AAA", "CCC")}
${TableRow($"[color=#ff0000][b]-232[/b][/color]"$, "AAA", "CCC")}
${TableRow($"[color=#ff0000][b]-232[/b][/color]"$, "AAA", "CCC")}
rbtn
"$
End Sub
Sub TableRow(Field1 As String, Field2 As String, Field3 As String) As String
Return $"[Span MinWidth=33%x Alignment=center]${Field1}[/Span][Span MinWidth=33%x Alignment=center]${Field2}[/Span][Span MinWidth=33%x Alignment=center]${Field3}[/Span]"$
End Sub
Sub btn_Click
Log("click")
End Sub
Sub BBCodeView1_LinkClicked (URL As String)
B4XPages.SetTitle(Me, URL)
End Sub
'************ B4i - adds a cancel action to touch events:
#if OBJC
@end
@interface B4IPanelView (touchcancelled)
@end
@implementation B4IPanelView (touchcancelled)
- (void)touchesCancelled:(NSSet *)touches withEvent:(UIEvent *)event {
B4I* bi = [self valueForKey:@"bi"];
NSString* eventName = [self valueForKey:@"eventName"];
for (UITouch *u in touches) {
CGPoint p = [u locationInView:self];
[bi raiseEvent:self event:eventName params:@[@4, @(p.x), @(p.y)]];
}
}
#End If
'**************************
