B4A Library [B4X] [XUI] nanoSvg Library (cross-platform)

nanoSvg Library
Support: B4A and B4J.

wrapper C/C++ nanoSvg (Gihub)

For B4J, copy the dll(x64) to B4J/Objects of the project.

NanoSVG is a simple stupid single-header-file SVG parse. The output of the parser is a list of cubic bezier shapes.
The library suits well for anything from rendering scalable icons in your editor application to prototyping a game.
NanoSVG supports a wide range of SVG features, but something may be missing, feel free to create a pull request!
The shapes in the SVG images are transformed by the viewBox and converted to specified units. That is, you should get the same looking data as your designed in your favorite app.

Dim svg As nanoSvg
svg.Initialize(B4XImageView1.mBase.Width, B4XImageView1.mBase.Height)

svg.Scale = 0.5
Dim imgRGBA() As Byte = svg.Render(File.ReadString(File.DirAssets, "23.svg"))

If imgRGBA.Length > 0 Then
    B4XImageView1.mBackgroundColor = 0
    B4XImageView1.Bitmap = nanoSvgAlphaBitmap(imgRGBA)
End If

' ***

svg.Width = B4XImageView2.mBase.Width
svg.Height = B4XImageView2.mBase.Height

svg.Scale = 0.8
svg.Align = 6
Dim imgRGBA() As Byte = svg.Render(File.ReadString(File.DirAssets, "telegram-plane.svg"))

If imgRGBA.Length > 0 Then
    B4XImageView2.mBackgroundColor = xui.Color_ARGB(255,255,255,255)
    B4XImageView2.Bitmap = nanoSvgAlphaBitmap(imgRGBA)
End If

Public Sub nanoSvgAlphaBitmap(img() As Byte) As B4XBitmap
    Dim w As Int = Bit.Or(Bit.And(img(img.Length-4) ,0xFF), Bit.ShiftLeft(Bit.And(img(img.Length-3) ,0xFF), 8))
    Dim h As Int = Bit.Or(Bit.And(img(img.Length-2) ,0xFF), Bit.ShiftLeft(Bit.And(img(img.Length-1) ,0xFF), 8))

    Dim bc As BitmapCreator
    bc.Initialize(w, h)

    Dim lick As Int
    For y = 0 To h - 1
        For x = 0 To w - 1
            bc.SetColor(x, y, xui.Color_ARGB( _
                Bit.And(0xff, img(lick + 3)), Bit.And(0xff, img(lick)), _
                Bit.And(0xff, img(lick + 1)), Bit.And(0xff, img(lick + 2))))
            lick = lick + 4
        Next
    Next
    Return bc.Bitmap
End Sub
