Android Question Best Connection with SQL Server 2022 Express?

jeronimovilar · Monday at 10:17 AM

How the best conection (fast and security) with Sql Server 2022 Express (windows)? I tryed JDBC (mssql-jdbc), but not connect

My MS SQL SERVER and Android App are in Intranet (192.168.0.xxx)

Chris2 · Monday at 2:01 PM

Have a look at jRDC2, which requires you to create a middleware server app (there are lots of project templates and examples in the forum).
If you prefer a direct database connection, look at the jdbcSQL tutorial.

jeronimovilar said:
I tryed JDBC (mssql-jdbc), but not connect

You'll need to post your connection code and the error messages in the logs if you expect people to be able to help with this.

jeronimovilar · 2026-01-07T12:32:03+0000

My code:

B4X:

#Region  Project Attributes
    #ApplicationLabel: Teste Extremo SQL
    #VersionCode: 1
    #VersionName: 1.0
    #SupportedOrientations: portrait
    #CanInstallToExternalStorage: False
    '#AdditionalJar: mssql-jdbc-9.4.1.jre11.jar
    #AdditionalJar: mssql-jdbc-12.8.1.jre8.jar
#End Region

Sub Process_Globals
    Public sql As JdbcSQL
    Private driver As String = "com.microsoft.sqlserver.jdbc.SQLServerDriver"
    Private testeEmAndamento As Boolean = False
    Private tentativa As Int = 1
End Sub

Sub Globals
    Private txtIP, txtPorta As EditText
    Private btnTestar, btnDiagnostico As Button
    Private lblStatus, lblDetalhes As Label
    Private ProgressBar1 As ProgressBar
    Private pnlConfig As Panel
End Sub

Sub Activity_Create(FirstTime As Boolean)
    Log("Iniciando aplicação...")
    Log("JAR SQL Server: mssql-jdbc-12.8.1.jre8.jar")

    Try
        ' Tenta carregar uma classe do driver para verificar
        Dim jo As JavaObject
        jo.InitializeStatic("com.microsoft.sqlserver.jdbc.SQLServerDriver")
        Log("Driver SQL Server OK!")
    Catch
        Log("ERRO: Não foi possível carregar o driver SQL Server")
        Log("Verifique se o JAR está em #AdditionalJar")
    End Try

    Activity.Color = Colors.White
    CriarLayoutExtremo

    txtIP.Text = "10.80.167.56"    ' "192.168.68.101"
    txtPorta.Text = "1434"
End Sub

Sub CriarLayoutExtremo
    Dim largura As Int = 100%x
    Dim margem As Int = 15dip
    Dim alturaItem As Int = 45dip
    Dim topo As Int = 20dip

    ' Painel
    pnlConfig.Initialize("")
    Activity.AddView(pnlConfig, 0, 0, largura, 100%y)
    pnlConfig.Color = Colors.White

    ' Título
    Dim lblTitulo As Label
    lblTitulo.Initialize("")
    pnlConfig.AddView(lblTitulo, 0, topo, largura, 40dip)
    lblTitulo.Text = "CONEXÃO EXTREMA SQL 2022"
    lblTitulo.TextSize = 16
    lblTitulo.Gravity = Gravity.CENTER
    lblTitulo.TextColor = Colors.Red
    topo = topo + 50dip

    ' IP
    Dim lblIP As Label
    lblIP.Initialize("")
    pnlConfig.AddView(lblIP, margem, topo, largura - 2*margem, 20dip)
    lblIP.Text = "IP do SQL Server 2022:"
    lblIP.TextSize = 12
    topo = topo + 25dip

    txtIP.Initialize("")
    pnlConfig.AddView(txtIP, margem, topo, largura - 2*margem, alturaItem)
    txtIP.Text = "192.168.68.101"
    topo = topo + alturaItem + 10dip

    ' Porta
    Dim lblPorta As Label
    lblPorta.Initialize("")
    pnlConfig.AddView(lblPorta, margem, topo, largura - 2*margem, 20dip)
    lblPorta.Text = "Porta TCP (1434):"
    lblPorta.TextSize = 12
    topo = topo + 25dip

    txtPorta.Initialize("")
    pnlConfig.AddView(txtPorta, margem, topo, 100dip, alturaItem)
    txtPorta.Text = "1434"
    topo = topo + alturaItem + 20dip

    ' Botões
    btnDiagnostico.Initialize("btnDiagnostico")
    pnlConfig.AddView(btnDiagnostico, margem, topo, (largura - 3*margem)/2, alturaItem)
    btnDiagnostico.Text = "TESTAR PORTA"
    btnDiagnostico.Color = Colors.Yellow

    btnTestar.Initialize("btnTestar")
    pnlConfig.AddView(btnTestar, 2*margem + (largura - 3*margem)/2, topo, (largura - 3*margem)/2, alturaItem)
    btnTestar.Text = "TESTE EXTREMO"
    btnTestar.Color = Colors.Red
    topo = topo + alturaItem + 20dip

    ' ProgressBar
    ProgressBar1.Initialize("")
    pnlConfig.AddView(ProgressBar1, margem, topo, largura - 2*margem, 15dip)
    ProgressBar1.Visible = False
    topo = topo + 25dip

    ' Status
    lblStatus.Initialize("")
    pnlConfig.AddView(lblStatus, margem, topo, largura - 2*margem, 50dip)
    lblStatus.Gravity = Gravity.CENTER
    lblStatus.TextSize = 16
    lblStatus.Text = "MODO EXTREMO ATIVADO"
    lblStatus.TextColor = Colors.Red
    topo = topo + 60dip

    ' Detalhes
    lblDetalhes.Initialize("")
    pnlConfig.AddView(lblDetalhes, margem, topo, largura - 2*margem, 300dip)
    lblDetalhes.TextSize = 11
    lblDetalhes.TextColor = Colors.DarkGray
    lblDetalhes.Text = "CONFIGURAÇÃO RADICAL SQL 2022:" & CRLF & _
                      "1. ForceEncryption: DISABLED" & CRLF & _
                      "2. TLS/SSL: DISABLED" & CRLF & _
                      "3. Protocolo: TCP apenas" & CRLF & _
                      "4. Compatibilidade: 2019" & CRLF & _
                      "5. Login: sa / surfbyte" & CRLF & _
                      "6. Banco: master" & CRLF & CRLF & _
                      "Executando 5 métodos extremos..."
End Sub

Sub btnDiagnostico_Click
    Dim ip As String = txtIP.Text.Trim
    If ip = "" Then ip = "10.80.167.56"

    Dim porta As String = txtPorta.Text.Trim
    If porta = "" Then porta = "1434"

    ProgressBar1.Visible = True
    lblStatus.Text = "Testando porta..."
    lblStatus.Color = Colors.Blue

    Dim resultado As String = TestarPorta(ip, porta)

    ProgressBar1.Visible = False

    If resultado = "OK" Then
        lblStatus.Text = "PORTA ABERTA"
        lblStatus.Color = Colors.Green
        lblDetalhes.Text = "Port " & porta & " OK!" & CRLF & _
                          "Server: " & ip & CRLF & _
                          "Ready for test."
    Else
        lblStatus.Text = "PORTA FECHADA"
        lblStatus.Color = Colors.Red
        lblDetalhes.Text = "Porta " & porta & " not ready." & CRLF & _
                          "ERRO: " & resultado & CRLF & CRLF & _
                          ""
    End If

    Log(DateTime.Time(DateTime.Now) & ": " & lblDetalhes.Text)
    Log(DateTime.Time(DateTime.Now) & ": " & lblStatus.Text)
End Sub

Sub TestarPorta(host As String, port As String) As String
    Try
        Dim portaInt As Int = port

        Dim socket As JavaObject
        socket.InitializeNewInstance("java.net.Socket", Null)

        Dim inetAddress As JavaObject
        inetAddress.InitializeStatic("java.net.InetAddress")
        Dim addr As JavaObject = inetAddress.RunMethod("getByName", Array(host))

        Dim socketAddress As JavaObject
        socketAddress.InitializeNewInstance("java.net.InetSocketAddress", Array(addr, portaInt))

        socket.RunMethod("connect", Array(socketAddress, 5000))

        Dim conectado As Boolean = socket.RunMethod("isConnected", Null)

        If conectado Then
            socket.RunMethod("close", Null)
            Return "OK"
        Else
            Return "Não conectado"
        End If

    Catch
        Return LastException.Message
    End Try
End Sub

Sub btnTestar_Click
    If testeEmAndamento Then Return

    Dim ipServidor As String = txtIP.Text.Trim
    Dim porta As String = txtPorta.Text.Trim

    If ipServidor = "" Then ipServidor = "192.168.68.101"
    If porta = "" Then porta = "1434"

    tentativa = 1
    testeEmAndamento = True
    btnTestar.Enabled = False
    btnDiagnostico.Enabled = False
    ProgressBar1.Visible = True

    ExecutarTesteExtremo(ipServidor, porta, 1)
End Sub

Sub ExecutarTesteExtremo(ipServidor As String, porta As String, metodo As Int)

    Dim url As String
    Dim usuario As String = "sa"
    Dim senha As String = "surfbyte"
    Dim banco As String = "SurfByte"

            ' MÉTODO 1: Forçar TLS 1.0 desabilitado COMPLETAMENTE
            url = "jdbc:sqlserver://" & ipServidor & ":" & porta & ";" & _
                  "databaseName=" & banco & ";" & _
                  "instance=SQLEXPRESS;" & _
                  "user=" & usuario & ";" & _
                  "password=" & senha & ";" & _
                  "encrypt=false;" & _
                  "trustServerCertificate=false;" & _
                  "loginTimeout=30;" & _
                  "sendStringParametersAsUnicode=true;" & _
                  "integratedSecurity=false;" & _
                  "authenticationScheme=NTLM;" & _
                  "jaasConfigurationName=SQLJDBCDriver;" & _
                  "trustStore=;" & _
                  "trustStorePassword=;" & _
                  "hostNameInCertificate=*;" & _
                  "serverNameAsACE=false;" & _
                  "xopenStates=false;" & _
                  "sendTimeAsDatetime=true;" & _
                  "packetSize=4096;" & _
                  "multiSubnetFailover=false"
            lblStatus.Text = "MÉTODO 1: TLS DESABILITADO"


    lblDetalhes.Text = "Método " & metodo & " de 5" & CRLF & _
                      "URL: " & url & CRLF & _
                      "Timeout: 30 segundos"

    Log(DateTime.Time(DateTime.Now) & ": " & "=== Starting... ===")
    Log(DateTime.Time(DateTime.Now) & ": " & "URL: " & url)

    If sql.IsInitialized Then sql.Close

    Try
        If url.Contains("user=") Then
            sql.InitializeAsync("SQL", driver, url, "", "")
        Else
            sql.InitializeAsync("SQL", driver, url, usuario, senha)
        End If

        Log(DateTime.Time(DateTime.Now) & ": " & "url  Start")

        ' Timeout longo
        Dim inicio As Long = DateTime.Now
        Do While DateTime.Now < inicio + 30000 And testeEmAndamento
            Sleep(100)
        Loop


    Catch
        Log(DateTime.Time(DateTime.Now) & ": " & "Error: " & LastException.Message)
'        ExecutarTesteExtremo(ipServidor, porta, metodo + 1)
    End Try
End Sub

Sub SQL_Ready (Success As Boolean)
    Log(DateTime.Time(DateTime.Now) & ": " & "SQL_Ready: " & Success)

    If Success Then
        ' CONSEGUIMOS!
        Try
            Dim cur As JdbcResultSet = sql.ExecQuery("SELECT @@VERSION as versao")

            If cur.NextRow Then
                Dim versao As String = cur.GetString("versao")
                cur.Close

                Dim versaoCurta As String = versao
                If versao.Length > 40 Then
                    versaoCurta = versao.SubString2(0, 40) & "..."
                End If

                FinalizarTeste(True, "SUCESSO NO MÉTODO " & tentativa & "!" & CRLF & CRLF & _
                             "SQL SERVER 2022 CONECTADO!" & CRLF & _
                             "Versão: " & versaoCurta & CRLF & CRLF & _
                             "Configuração que funcionou:" & CRLF & _
                             lblStatus.Text)
            Else
                cur.Close
                FinalizarTeste(True, "CONECTADO! Método " & tentativa)
            End If

        Catch
            FinalizarTeste(True, "CONECTADO! Erro consulta:" & CRLF & _
                         LastException.Message)
        End Try
    Else
        ' Falha - próximo método
        Dim erro As String = LastException.Message
        Log(DateTime.Time(DateTime.Now) & ": " & "Fail " & tentativa & ": " & erro)

        Dim ipServidor As String = txtIP.Text.Trim
        Dim porta As String = txtPorta.Text.Trim

        'ExecutarTesteExtremo(ipServidor, porta, tentativa + 1)
    End If
End Sub

Sub FinalizarTeste(sucesso As Boolean, mensagem As String)
    testeEmAndamento = False
    btnTestar.Enabled = True
    btnDiagnostico.Enabled = True
    ProgressBar1.Visible = False

    If sucesso Then
        lblStatus.Text = "CONEXÃO EXTREMA OK!"
        lblStatus.Color = Colors.Green
    Else
        lblStatus.Text = "FALHA TOTAL"
        lblStatus.Color = Colors.Red
    End If

    lblDetalhes.Text = mensagem
End Sub

Sub Activity_Resume

End Sub

Sub Activity_Pause (UserClosed As Boolean)
    If sql.IsInitialized Then
        sql.Close
    End If
End Sub

LOG:

Iniciando aplicação...
JAR SQL Server: mssql-jdbc-12.8.1.jre8.jar
Driver SQL Server OK!
09:28:27: Port 1434 OK!
Server: 10.80.167.56
Ready for test.
09:28:27: PORTA ABERTA
09:28:27: === Starting... ===
09:28:27: URL: jdbc:sqlserver://10.80.167.56:1434;databaseName=SurfByte;instance=SQLEXPRESS;user=sa;password=surfbyte;encrypt=false;trustServerCertificate=false;loginTimeout=30;sendStringParametersAsUnicode=true;integratedSecurity=false;authenticationScheme=NTLM;jaasConfigurationName=SQLJDBCDriver;trustStore=;trustStorePassword=;hostNameInCertificate=*;serverNameAsACE=false;xopenStates=false;sendTimeAsDatetime=true;packetSize=4096;multiSubnetFailover=false
09:28:27: url Start
09:30:24: SQL_Ready: false
09:30:24: Fail 1: java.io.IOException: Connection reset ClientConnectionId:daa38001-ab71-4ac1-b439-af4ed4a3e94c
