B4J Code Snippet Color Blend Effect

B4X:
Sub Process_Globals
    Private fx As JFX
    Private MainForm As Form
    Private xui As XUI
    Private Button1 As B4XView
    Private jStage As JavaObject
    Private root As JavaObject
    Private Circle As JavaObject
    Private blend As JavaObject
    Private topInput As JavaObject
    Dim blenMode As JavaObject

End Sub

Sub AppStart (Form1 As Form, Args() As String)
    MainForm = Form1
    MainForm.RootPane.LoadLayout("Layout1")
    MainForm.Show
    jStage=MainForm.As(JavaObject).GetFieldJO("stage")

    Circle.InitializeNewInstance("javafx.scene.shape.Circle",Null)

    Circle.RunMethod("setCenterX",Array(75.0))
    Circle.RunMethod("setCenterY",Array(75.0))

    Circle.RunMethod("setRadius",Array(100.0))
    Circle.RunMethod("setFill",Array(fx.Colors.green)) 'RGB(161,22,22)))

    blend.InitializeNewInstance("javafx.scene.effect.Blend",Null)
    topInput.InitializeNewInstance("javafx.scene.effect.ColorInput",Null)
    topInput.RunMethod("setHeight",Array(155.0))
    topInput.RunMethod("setWidth",Array(150.0))
    topInput.RunMethod("setX",Array(-40.0))
    topInput.RunMethod("setY",Array(30.0))
    topInput.RunMethod("setPaint",Array(fx.Colors.Red)) '.RGB(130, 15, 190)))
'    //setting the top input To the blend object
    blend.RunMethod("setTopInput",Array(topInput))
'    //setting the blend mode
    blenMode.InitializeStatic("javafx.scene.effect.BlendMode")
    blend.RunMethod("setMode",Array(blenMode.GetField("DIFFERENCE")))

'    //Applying the blend effect To Circle
    Circle.RunMethod("setEffect", Array(blend))
    root.InitializeNewInstance("javafx.scene.Group",Null)
    root.RunMethodJO("getChildren",Null).RunMethod("add",Array(Circle))

    MainForm.RootPane.AddNode(root,200dip,200dip,0,0)


End Sub
