iOS Question Descriptors iBLE?

[f0raster0]

Hi,
What should I add to my code to read the entire list of descriptors?

Example:
service: 181A -> Characteristics: 2A6F, 2A6D -> Descriptors: 2901, 290B, ....

Sub Environmental_Sensing(Characteristics As Map)
    For Each id As String In Characteristics.Keys
        'Log(Characteristics.Get(id))
        If id = "2A6F" Then
           ' descriptors¿?

        End If

        If id = "2A6D" Then

            ' descriptors¿?

        End If
    Next
End Sub

Sub Button12_Click
'-----------------------notiffication state ON ------------------------------------
'    'Environmental_Sensing
'    manager.SetNotify("181A","2A6F",True) 'Humidity
    manager.SetNotify("181A","2A6D",True) 'Pressure


End Sub



[Erel]

Try this:

Dim no As NativeObject = manager
Dim service As Object = no.RunMethod("getService:", Array("<service id>"))
Dim c As NativeObject = no.RunMethod("getChar::", Array(service, "<characteristic id>"))
Log(c.GetField("descriptors"))



[f0raster0]

Thanks, I got this error:

Services discovery completed.
UUID: 181A
Error occurred on line: 172 (Main)
Method not found: getService:, target: <CBCentralManager: 0x156cbe10>
Stack Trace: (
CoreFoundation <redacted> + 150
libobjc.A.dylib objc_exception_throw + 38
CoreFoundation <redacted> + 0

'//// Environmental - Sensing ////
Sub Environmental_Sensing(Characteristics As Map)
    For Each id As String In Characteristics.Keys
        'Log(Characteristics.Get(id))
        If id = "2A6D" Then
            Dim no As NativeObject = manager
            Dim service As Object = no.RunMethod("getService:", Array("<service id>")) 'line172
            Dim c As NativeObject = no.RunMethod("getChar::", Array(service, "<characteristic id>"))
            Log(c.GetField("descriptors"))
        End If
    Next
End Sub

Note: B4i v2.31, iBLE library 2.31



[Erel]

1. You need to change <service id> and <characteristic id> with the actual values.
2.
Change the code to:

Dim no As NativeObject
no.Initialize("BleManager")
no.SetField("object", manager")
Dim service As Object = no.RunMethod("getService:", Array("<service id>"))
Dim c As NativeObject = no.RunMethod("getChar::", Array(service, "<characteristic id>"))
Log(c.GetField("descriptors"))

I haven't tested it.



[f0raster0]

Thanks, I got this error:

[<BleManager 0x186554> setValue:forUndefinedKey:]: this class is not key value coding-compliant for the key object.
and if I try again I got:
[<BleManager 0xf5554> setValue:forUndefinedKey:]: this class is not key value coding-compliant for the key object.

Sub Environmental_Sensing(Characteristics As Map)
    For Each id As String In Characteristics.Keys
        'Log(Characteristics.Get(id))
        If id = "2A6D" Then
            Dim no As NativeObject
            no.Initialize("BleManager")
            no.SetField("object", "manager")
            'no.SetField("object", manager)
            Dim service As Object = no.RunMethod("getService:", Array("181A"))
            Dim c As NativeObject = no.RunMethod("getChar::", Array(service, "2A6D"))
            Log(c.GetField("descriptors"))
       End If
    Next
End Sub



[f0raster0]

What does it error mean?

Error occurred on line: 174 (Main)
[<BleManager 0xbc780> setValue:forUndefinedKey:]: this class is not key value coding-compliant for the key object.

line 174 in code above:
no.SetField("object", "manager")



[Erel]

It should be:

Dim no As NativeObject
no = no.Initialize("BleManager").RunMethod("new", Null)
no.SetField("object", manager)
Dim service As Object = no.RunMethod("getService:", Array("<service id>"))
Dim c As NativeObject = no.RunMethod("getChar::", Array(service, "<characteristic id>"))
Log(c.GetField("descriptors"))



[f0raster0]

Thanks Erel, I couldn't read anything.. the result is: null
not sure why.. at the moment I had tried with all the services that I'm reading but always the result is: null



[Erel]

Update to iBLE v1.40: https://www.b4x.com/android/forum/threads/updates-to-internal-libraries.48179/page-3

You can then run this code:

'discover the descriptors
Dim per As NativeObject = manager.GetPeripheralObject
per.RunMethod("discoverDescriptorsForCharacteristic:", Array(manager.GetCharacteristicObject(<service id>, <char id>))

After a few seconds you can check the descriptors:

Dim c As NativeObject = manager.GetCharacteristicObject(...)
Log(c.GetField("descriptors"))
