Android Question Help with Image please

[werner_Fourie]

Hi All..

I have an image which represents a dial from x value to y value where the first part of the image is x and the last part of the image is y ..
What i want to do is by pressing an up or down button only the image part representing that setting must be displayed in a panel..

I think it has to to with sprites but I am not familiar on how it works..

Can any body please help..It would be much appreciated..

Thanks..



[Erel]

Why not use https://www.b4x.com/android/forum/t...ogress-bar-with-gradient-fill.104476/#content ?



[werner_Fourie]

Why not use https://www.b4x.com/android/forum/t...ogress-bar-with-gradient-fill.104476/#content ?

Hi Erel

I use JKnobman to create different dials and sliders for my projects..
I prefer to use it..
Makes the interface looks better..
I can split the image it into different single images.. BUT..
I would prefer to move the single image into position according to the value needed as per the image..

Still pray for some help..

Thanks anyway..



[werner_Fourie]

Just a small comment on what the image is..

It is used as a dial on the screen where an operator dials in a preset ..



[Erel]

Something like:

Dim original As B4XBitmap = xui.LoadBitmap(...)
Dim images As List
images.Initialize
For i = 0 to 20
 images.Add(original.Crop(0, i * SpriteHeight, original.Width, SpriteHeight)
Next

Later you can get an image with:

Dim b As B4XBitmap = images.Get(13)



[Star-Dust]

Why not use https://www.b4x.com/android/forum/t...ogress-bar-with-gradient-fill.104476/#content ?

@werner_Fourie I think i believe you can follow @Erel's suggestion without giving up the image made with JKnobman.

I would put the JKnobman image in an ImageView and above a CustomView with a transparent background that realizes the green bar and the percentage number.

However, the image created with JKnobman can also be created from code



[kimstudio]

I used to use JKnobman in Windows programming. Usually you load the whole knob image and copy part of the image into your view. B4A Canvas.DrawBitmap does support SrcRect and DestRect, I believe you can just use it.



[werner_Fourie]

You are all stars..

Thank You for the input..

@Erel's suggestion worked..

thanks
