Android Question How to pixelate images

[Mashiane]

Hi

I want to be able to pixelate images, is there anyone who can advise me on how to do this please.

Thanks



[Roycefer]

The simplest way is to open the image using LoadBitmapSample and use a really small resolution and then blow it back up to the original resolution. It will be heavily pixelated.

If you want to do it computationally, divide your picture up into a grid where each grid is the size of the new "pixel" you will create. Then go through each grid and calculate the average red value, green value, and blue value of all the pixels within the grid. Then create a new color based on these average values and set all the corresponding pixels in your output image to that color. This is the most naive method of pixelation.

There are more sophisticated methods like Gaussian blur that you can look into.

Here's a library that does some interesting stuff: https://www.b4x.com/android/forum/threads/rsimageprocessing-library.16230/#content



[Informatix]

Do you want to pixelate an image in real time? Just process it once?

You have a pixelation demo here that you can apply in real time but this solution requires to use libGDX.



[Mashiane]

Do you want to pixelate an image in real time? Just process it once?

You have a pixelation demo here that you can apply in real time but this solution requires to use libGDX.

Thanks, just once and save that into a file. I will check the demo.



[Mashiane]

The simplest way is to open the image using LoadBitmapSample and use a really small resolution and then blow it back up to the original resolution. It will be heavily pixelated.

If you want to do it computationally, divide your picture up into a grid where each grid is the size of the new "pixel" you will create. Then go through each grid and calculate the average red value, green value, and blue value of all the pixels within the grid. Then create a new color based on these average values and set all the corresponding pixels in your output image to that color. This is the most naive method of pixelation.

There are more sophisticated methods like Gaussian blur that you can look into.

Here's a library that does some interesting stuff: https://www.b4x.com/android/forum/threads/rsimageprocessing-library.16230/#content

Thanks, will check the library out.



[JordiCP]

Also, canvas can do the trick by drawing to a smaller bitmap and then drawing the result to another with the same size as the original

Before After

Sub Pixelate(B0 As Bitmap) as Bitmap

  Dim factor As Float=8    'Change it to get different pixellations

  Dim new_w As Int = B0.Width/factor
  Dim new_h As Int = B0.Height/factor

  If new_w>=1 And new_h>=1 Then

    'Draw the original onto a smaller one
    Dim B_small As Bitmap
    B_small.InitializeMutable(new_w,new_h)
    Dim cv As Canvas
    cv.Initialize2(B_small)
    Dim DestRect As Rect
    DestRect.Initialize(0,0,B_small.Width,B_small.Height)
    cv.DrawBitmap(B0,Null,DestRect)

    'Create a new bitmap wth the same dimensions as the original
    Dim B_pixelated as Bitmap
    B_pixelated.initializemutable(B0.width,B0.Height)
    cv.Initialize2(B_pixelated)
    Dim DestRect As Rect
    DestRect.Initialize(0,0,B_pixelated.Width,B_pixelated.Height)
    cv.DrawBitmap(B_small,Null,DestRect)

    return B_pixelated

  Else
   return B0

  End If

End Sub



[Mashiane]

Also, canvas can do the trick by drawing to a smaller bitmap and then drawing the result to another with the same size as the original

Before View attachment 38554 After View attachment 38555

Sub Pixelate(B0 As Bitmap) as Bitmap

  Dim factor As Float=8    'Change it to get different pixellations

  Dim new_w As Int = B0.Width/factor
  Dim new_h As Int = B0.Height/factor

  If new_w>=1 And new_h>=1 Then

    'Draw the original onto a smaller one
    Dim B_small As Bitmap
    B_small.InitializeMutable(new_w,new_h)
    Dim cv As Canvas
    cv.Initialize2(B_small)
    Dim DestRect As Rect
    DestRect.Initialize(0,0,B_small.Width,B_small.Height)
    cv.DrawBitmap(B0,Null,DestRect)

    'Create a new bitmap wth the same dimensions as the original
    Dim B_pixelated as Bitmap
    B_pixelated.initializemutable(B0.width,B0.Height)
    cv.Initialize2(B_pixelated)
    Dim DestRect As Rect
    DestRect.Initialize(0,0,B_pixelated.Width,B_pixelated.Height)
    cv.DrawBitmap(B_small,Null,DestRect)

    return B_pixelated

  Else
   return B0

  End If

End Sub

@JordiCP - thanks, perfect, you just made my day!
