B4R Library OneWire - Dallas 1-wire protocol

Sub Process_Globals
   Public Serial1 As Serial
   Private onewire As OneWire
   Private timer1 As Timer
   Private bc As ByteConverter
   Private address(8) As Byte
   Private type_s As Boolean
End Sub

Private Sub AppStart
   Serial1.Initialize(115200)
   Log("AppStart")
   onewire.Initialize(10)
   timer1.Initialize("timer1_Tick", 2000)
   timer1.Enabled = True
End Sub

Sub Timer1_Tick
   If onewire.Search(address) = False Then
     onewire.ResetSearch
     Log("No more addresses.")
     Return
   End If
   Log("ROM = ", bc.HexFromBytes(address))
   If onewire.CRC8(address, 7) <> address(7) Then
     Log("CRC is not valid!")
     Return
   End If
   Select address(0)
     Case 0x10
       Log("Chip = DS18S20")
       type_s = True
     Case 0x28
       Log("Chip = DS18B20")
       type_s = False
     Case 0x22
       Log("Chip = DS1822")
       type_s = False
     Case Else
       Log("Device is not a DS18x20 family device.")
       Return
   End Select
   onewire.Reset
   onewire.Select(address)
   onewire.Write(0x44, True)
   'give it 1 second to read the temperature
   CallSubPlus("ReadTemparature", 1000, 0)
End Sub

Private Sub ReadTemparature (u As Byte)
   onewire.Reset
   onewire.Select(address)
   onewire.Write(0xBE, False)
   Dim data(12) As Byte
   onewire.ReadBytes(data, 9)
   Log("Data = ", bc.HexFromBytes(data))
   Log("CRC = ", bc.HexFromBytes(Array As Byte(onewire.CRC8(data, 8))))
   Dim raw As Int = Bit.Or(Bit.ShiftLeft(data(1), 8), data(0))
   If type_s Then
     raw = Bit.ShiftLeft(raw, 3)
     If data(7) = 0x10 Then
       raw = Bit.And(raw, 0xFFF0) + 12 - data(6)
     End If
   Else
     Dim cfg As Byte = Bit.And(data(4), 0x60)
     If cfg = 0 Then
       raw = Bit.And(raw, Bit.Not(7))
     Else if cfg = 0x20 Then
       raw = Bit.And(raw, Bit.Not(3))
     Else if cfg = 0x40 Then
       Bit.And(raw, Bit.Not(1))
     End If
   End If
   Dim celsius As Double = raw / 16
   Dim fahrenheit As Double = celsius * 1.8 + 32
   Log("Temperature = ", NumberFormat(celsius, 0, 2), " Celsius, " _
     , NumberFormat(fahrenheit, 0, 2), " Fahrenheit")
End Sub
