B4A Library UISwitch - Switch Control (iOS like)

This library was made based on UISwitch for IOS

Installation instructions:
- Copy the .xml and .jar files to your custom libraries folder
- Select in your REFERENCED LIBRARIES

Version history:
V1.0 (First public release):
- Initial version

UISwitch
Author: Alberto Iglesias
Version: 1

• UISwitch
  Methods:
  • IsInitialized As Boolean
    Tests whether the object has been initialized.
  • _asview As PanelWrapper
    Return Panel Object from UISwitch
  • _author As String
    Return the author of this library
  • _getposition As String
    Return the Position
  • _initialize (vCallback As Object, ev As String, Tag As String, Width As Int, Height As Int, Bitmap0 As BitmapWrapper, Bitmap1 As BitmapWrapper) As String
    Initializes the object. You can add parameters to this method if needed.

    Examples:

    Dim objBmp0 As Bitmap = LoadBitmap(File.DirAssets, "Model01_OFF.png")
    Dim objBmp1 As Bitmap = LoadBitmap(File.DirAssets, "Model01_ON.png")
    objUISwitch3.Initialize(Me,"objUISwitch","3333333",154dip,54dip,objBmp0,objBmp1)
  • _setposition (pPosition As Int) As String
    Set Position (0 or 1)
  • _version As String
    Return the version of this library

This library use the AnimationPlus like dependence, if you don´t have, do the download from
http://www.b4x.com/android/forum/threads/lib-animationplus.21313/



[CidTek]

Incredible! You must have been up all night working on this and I thank you very much!

I will be working with the samples tonight and I will post back some feedback.



[CidTek]

Here is a couple more png files that are Blackberry themed.



[Erel]

Great work! Thank you for sharing.



[WizardOz]

This got GOOD pretty fast! Great work!



[LucaMs]

The "circles" in the main image are almost perfect, in the other pictures posted no.

I am afraid that there is no method to scale images without distorting them.
I think we should use the folders for the various resolutions such as Google suggests and this is really a nuisance.



[palmzac]

Great Lib. Thanks !



[LucaMs]

It don't work on B4A v3.20

java.lang.NoSuchMethodError: anywheresoftware.b4a.BA.isShellModeRuntimeCheck



[JakeBullet70]

Very nice. Thanks



[Alberto Iglesias]

You can put any images in your code, this is some examples I included with library.

You can adjust putting transparent in border of any image or creating your own image.

Thanks



[CidTek]

I have added this custom view to my app to replace checkboxes and it works perfect and looks great. Just remember to keep the height and width ratios correct when using any image or else it will get distorted.

I am confused by the AnimationPlus requirement as it doesn't seem to be needed and the sample projects didn't reference it either.

Thanks again for a great library!



[cd37ycs]

Great work!



[Tom Christman]

Really Nice work Thank you!



[tianya]

Thank you!



[Silv]

Hi Alberto, is your library works fine with Android 5? I just run yours examples and i see only the blank screen.
Thanks



[Silv]

Oh i fixed it, i just forget to update my AnimationPlus library. Would be great if in new versions of B4A existing libraries start updating automatically.



[hears]

i have tried ,this switch cannot set to off by this code ,if setposition always display ON.
why ?

objUI1.SetPosition(0)
objUI2.SetPosition(1)



[Alberto Iglesias]

i have tried ,this switch cannot set to off by this code ,if setposition always display ON.
why ?

objUI1.SetPosition(0)
objUI2.SetPosition(1)

I will check today, dont worry
