Hi Fam

I am pleased to present B4XDashboard, a nativecross-platform component part of the B4X Daisy UI Kit series.

Inspired by the clean utility of the Tailwind CSS / DaisyUIframework, this component provides a fully responsive, paged "Launcher" style interface for your apps. It is perfect for main menus, app drawers, or tool grids. It is built purely with native B4X views (Canvas/Panels) for maximum performance—no WebViews required.

The "Glue": B4XDaisyVariants Like all components in this series, B4XDashboard relies on B4XDaisyVariants. Thisshared code module acts as the styling engine, handling color palettes, shape normalization, and utility sizes to ensure your dashboard looks consistent with other Daisy UI Kit components.


Key Features

• Auto-Grid Layout: Automatically calculates theoptimal number of rows and columns based on the available screen size and your defined MinCellWidth / MinCellHeight.

• Pagination: Built-in horizontal swipe navigationwith customizable page indicator dots.

• Notification Badges: Supports native-style badges(counters) on icons. It automatically handles "99+" truncation for large numbers.

• Flexible Content: Supports Bitmaps, SVGs (viabitmap conversion), Labels, and Background Wallpapers.

• Dynamic Updates: Update labels, icons, or badges atruntime without flickering.

🛠 Dependencies

1. B4XDaisyVariants.bas (Static Code Module) - Includedin the attachment

Usage Example

1. Designer Configuration: Add the B4XDashboard toyour layout.

• Auto Grid: Checked (Recommended)

• Min Cell Width/Height: 72 (default)

• Active/Inactive Dot Color: Customize to match yourtheme.

Designer Properties

• AutoGrid: If true, ignores explicit row/columncounts and calculates them based on the view size.

• RowsPerPage / ColumnsPerPage: Used if AutoGrid isdisabled.

• PagePadding / CellSpacing: Control the density ofthe grid.

• BackgroundImage: Set a wallpaper behind the icons.

• ActiveIndicatorColor: Color of the dot for thecurrent page.

Sub Globals
    Private Dashboard As B4XDashboard
End Sub

Sub Activity_Create(FirstTime As Boolean)
    Activity.LoadLayout("MainLayout")

    ' Add items dynamically
    ' Parameters: ID, Label, ImageFileName, SvgFileName (Empty string if unused)
    Dashboard.AddButton("btn_profile", "My Profile", "user.png", "")
    Dashboard.AddButton("btn_settings", "Settings", "gear.png", "")
    Dashboard.AddButton("btn_messages", "Messages", "mail.png", "")

    ' Or add using specific path helper
    Dashboard.AddButtonWithImagePath("btn_camera", "Camera", File.Combine(File.DirAssets, "cam.jpg"))

    ' Update a badge at runtime (e.g., incoming message)
    Dashboard.UpdateButtonBadge("btn_messages", 5)

    ' Update to "99+" automatically
    Dashboard.UpdateButtonBadge("btn_settings", 120)
End Sub

' Handle Clicks
Sub Dashboard_ButtonClick(ButtonId As String, ButtonDef As Map)
    Log("User clicked: " & ButtonId)

    Select Case ButtonId
        Case "btn_messages"
            ' Clear badge on click
            Dashboard.UpdateButtonBadge(ButtonId, 0)
    End Select
End Sub

' Optional: Monitor Page Changes
Sub Dashboard_PageChanged(PageIndex As Int, PageCount As Int)
    Log($"Scrolled to page ${PageIndex} of ${PageCount}"$)
End Sub

.... a continuing story...
