[B4X] PocketBase - Open Source backend in 1 file

PocketBase was created to assist building self-contained applications that can run on a single server without requiring to install anything in addition.
The basic idea is that the common functionality like crud, auth, files upload, auto TLS, etc. are handled out of the box, allowing you to focus on the UI and your actual app business requirements.

Please note that PocketBase is neither a startup, nor a business. There is no paid team or company behind it. It is a personal open source project with intentionally limited scope and developed entirely on volunteer basis. There are no promises for maintenance and support beyond what is already available

PocketBase - Open Source backend in 1 file

Open Source backend in 1 file with realtime database, authentication, file storage and admin dashboard

pocketbase.io

----------------------------------------------------------------------------------------------------------------------------------------------------------------------------

After writing the Supabase client library for B4X, it's now time for a simpler self-hosting variant, for smaller projects that need a backend, but you don't want to write a complex API. Again, the goal is to get mentioned on the official Github repo with the B4X-Pocketbase library.

GitHub - StolteX/B4X-PocketBase

Contribute to StolteX/B4X-PocketBase development by creating an account on GitHub.

github.com

Roadmap

Authentification (Social Login)
- Signin with Google
- Signin with Apple
- OTP
- Sign In Anonymously
Database
- Batch
- Realtime
Storage
- Download with progress

Examples and Tutorials
-Soon

PocketBase
Author: Alexander Stolte
Version: 1.00

Pocketbase
- Events:
  - AuthStateChange (StateType As String)
  - RangeDownloadTracker (Tracker As PocketbaseRangeDownloadTracker)
- Functions:
  - Initialize (URL As String)
    Initializes the object. You can add parameters to this method if needed.
  - InitializeEvents (Callback As Object, EventName As String)
- Properties:
  - Auth As Pocketbase_Authentication [read only]
  - Database As Pocketbase_Database [read only]
  - LogEvents As Boolean
  - Storage As Pocketbase_Storage [read only]
  - URL As String [read only]
Pocketbase_Authentication
- Functions:
  - ConfirmEmailChange (Token As String, Password As String) As ResumableSub
    Confirms the password reset with the verification token from the e-mail
    <code>
    Wait For (xPocketbase.Auth.ConfirmEmailChange("xxx","Test123!")) Complete (Response As PocketbaseError)
    If Response.Success Then
    Log("E-Mail change successfully")
    Else
    Log("Error: " & Response.ErrorMessage)
    End If
    </code>
  - ConfirmPasswordReset (Token As String, NewPassword As String, NewPasswordConfirm As String) As ResumableSub
    Confirms the password reset with the verification token from the e-mail
    <code>
    Wait For (xPocketbase.Auth.ConfirmPasswordReset("xxx","Test123!","Test123!")) Complete (Response As PocketbaseError)
    If Response.Success Then
    Log("Password change successfully")
    Else
    Log("Error: " & Response.ErrorMessage)
    End If
    </code>
  - ConfirmVerification (VerificationToken As String) As ResumableSub
    Confirms the user account with the verification token from the e-mail
    <code>
    Wait For (xPocketbase.Auth.ConfirmVerification("xxx")) Complete (Success As PocketbaseError)
    If Success.Success Then
    Log("verification sucessfull")
    Else
    Log("Error: " & Success.ErrorMessage)
    End If
    </code>
  - DeleteUser As ResumableSub
    Delete a single users record
    <code>Wait For (xPocketbase.Auth.DeleteUser) Complete (Success As PocketbaseError)</code>
  - GetAccessToken As ResumableSub
  - GetUser As ResumableSub
    Gets the user object
    <code>Wait For (xPocketbase.Auth.GetUser) Complete (User As PocketbaseUser)</code>
  - Initialize (ThisPocketbase As Pocketbase, EventName As String)
    Initializes the object. You can add parameters to this method if needed.
  - isUserLoggedIn As ResumableSub
    Checks if the user is logged in, renews the access token if it has expired
    <code>Wait For (xPocketbase.Auth.isUserLoggedIn) Complete (isLoggedIn As Boolean)</code>
  - Login_EmailPassword (Email As String, Password As String) As ResumableSub
    Authenticate with combination of email and password
    <code>
    Wait For (xPocketbase.Auth.LogIn_EmailPassword("test@example.com","Test123!")) Complete (User As PocketbaseUser)
    If User.Error.Success Then
    Log("successfully logged in with " & User.Email)
    Else
    Log("Error: " & User.Error.ErrorMessage)
    End If
    </code>
  - Logout As ResumableSub
    User tokens and infos are removed from the device
  - RefreshToken As ResumableSub
  - RequestEmailChange (NewEmail As String) As ResumableSub
    Sends users email change request
    On successful email change all previously issued auth tokens for the specific record will be automatically invalidated
    <code>
    Wait For (xPocketbase.Auth.RequestEmailChange("test@example.com")) Complete (Success As PocketbaseError)
    If Success.Success Then
    Log("E-Mail change request sent")
    Else
    Log("Error: " & Success.ErrorMessage)
    End If
    </code>
  - RequestPasswordReset (Email As String) As ResumableSub
    Sends users password reset email request
    On successful password reset all previously issued auth tokens for the specific record will be automatically invalidated
    <code>
    wait for (xPocketbase.Auth.PasswordRecovery("test@example.com")) Complete (Response As PocketbaseError)
    If Response.Success Then
    Log("Recovery email sent successfully")
    Else
    Log("Error: " & Response.ErrorMessage)
    End If
    </code>
  - RequestVerification (Email As String) As ResumableSub
    Sends users account verification request
    <code>
    Wait For (xPocketbase.Auth.RequestVerification("test@example.com")) Complete (Success As PocketbaseError)
    If Success.Success Then
    Log("verification code send to email")
    Else
    Log("Error: " & Success.ErrorMessage)
    End If
    </code>
  - SaveToken
  - SignUp (Email As String, Password As String, PasswordConfirm As String, Options As Map) As ResumableSub
    Allow your users to sign up and create a new account.
    Options - Optional fields
    A full list of values you find in the dashboard in the “API Preview” in the “users” collection
    <code>
    Wait For (xPocketbase.Auth.SignUp("test@example.com","Test123!","Test123!",Null)) Complete (NewUser As PocketbaseUser)
    If NewUser.Error.Success Then
    Log("successfully registered with " & NewUser.Email)
    Else
    Log("Error: " & NewUser.Error.ErrorMessage)
    End If
    </code>
  - UpdateUser (Options As Map) As ResumableSub
    Update a single users record
    A full list of values you find in the dashboard in the “API Preview” in the “users” collection
    <code>Wait For (xPocketbase.Auth.UpdateUser(CreateMap("name":"Test Name"))) Complete (Success As PocketbaseError)</code>
- Properties:
  - TokenInformations As PocketbaseTokenInformations [read only]
  - UserCollectionName As String
    Change it only if you change the default "users" table name
Pocketbase_Database
- Functions:
  - DeleteData As Pocketbase_DatabaseDelete
    Delete a single collection record
    <code>Wait For (xPocketbase.Database.DeleteData.Collection("dt_Task").Execute("43r7071wtp30l5h")) Complete (Result As PocketbaseError)</code>
  - Initialize (ThisPocketbase As Pocketbase)
    Initializes the object. You can add parameters to this method if needed.
  - InsertData As Pocketbase_DatabaseInsert
    <code>
    Dim Insert As Pocketbase_DatabaseInsert = xPocketbase.Database.InsertData.Collection("dt_Task")
    Insert.Parameter_Fields("Task_Name,Task_CompletedAt")
    Dim InsertMap As Map = CreateMap("Task_UserId":xPocketbase.Auth.TokenInformations.Id,"Task_Name":"Task 01","Task_CompletedAt"ocketbase_Functions.GetISO8601UTC(DateTime.Now))
    Wait For (Insert.Insert(InsertMap).Execute) Complete (DatabaseResult As PocketbaseDatabaseResult)
    xPocketbase.Database.PrintTable(DatabaseResult)
    </code>
  - PrintTable (Table As PocketbaseDatabaseResult)
  - SelectData As Pocketbase_DatabaseSelect
    <code>
    Wait For (xPocketbase.Database.SelectData.Collection("dt_Task").GetList(0,2,"")) Complete (DatabaseResult As PocketbaseDatabaseResult)
    xPocketbase.Database.PrintTable(DatabaseResult)
    </code>
  - UpdateData As Pocketbase_DatabaseUpdate
    <code>
    Dim UpdateRecord As Pocketbase_DatabaseUpdate = xPocketbase.Database.UpdateData.Collection("dt_Task")
    UpdateRecord.Parameter_Fields("Task_Name,Task_CompletedAt")
    UpdateRecord.Update(CreateMap("Task_Name":"Task 02"))
    Wait For (UpdateRecord.Execute("77avq8zn44ck37m")) Complete (DatabaseResult As PocketbaseDatabaseResult)
    xPocketbase.Database.PrintTable(DatabaseResult)
    </code>
Pocketbase_DatabaseDelete
- Functions:
  - Collection (TableName As String) As Pocketbase_DatabaseDelete
  - Execute (RecordId As String) As ResumableSub
  - Initialize (ThisPocketbase As Pocketbase)
    Initializes the object. You can add parameters to this method if needed.
Pocketbase_DatabaseInsert
- Functions:
  - Collection (TableName As String) As Pocketbase_DatabaseInsert
  - Execute As ResumableSub
  - Initialize (ThisPocketbase As Pocketbase)
    Initializes the object. You can add parameters to this method if needed.
  - Insert (ColumnValue As Map) As Pocketbase_DatabaseInsert
    Insert one row
    <code>Dim InsertMap As Map = CreateMap("Tasks_Name":"Task 01","Tasks_Checked":True,"Tasks_CreatedAt"ateUtils.TicksToString(DateTime.Now))</code>
  - Parameter_Expand (Expand As String) As Pocketbase_DatabaseInsert
    Auto expand record relations.
  - Parameter_Fields (Fields As String) As Pocketbase_DatabaseInsert
    Comma separated string of the fields to return in the JSON response (by default returns all fields).
    <code>CustomQuery.Parameter_Fields("Task_Name,Task_CompletedAt")</code>
  - Parameter_Files (Files As List)
Pocketbase_DatabaseSelect
- Functions:
  - Collection (TableName As String) As Pocketbase_DatabaseSelect
  - GetCustom
    Create your own query with all available filters
    Use the "Parameter_" properties
    <code>
    Dim CustomQuery As Pocketbase_DatabaseSelect = xPocketbase.Database.SelectData.Collection("dt_Task")
    CustomQuery.Parameter_Page(0)
    CustomQuery.Parameter_PerPage(2)
    CustomQuery.Parameter_Fields("Task_Name,Task_CompletedAt")
    CustomQuery.Parameter_Sort("-Task_Name") 'DESC
    Wait For (CustomQuery.GetCustom) Complete (DatabaseResult As PocketbaseDatabaseResult)
    xPocketbase.Database.PrintTable(DatabaseResult)</code>
  - GetFirstListItem (Filter As String, Expand As String) As ResumableSub
    Returns the first found list item by the specified filter.
    <code> Wait For (xPocketbase.Database.SelectData.Collection("dt_Task").GetFirstListItem("","")) Complete (DatabaseResult As PocketbaseDatabaseResult)
    xPocketbase.Database.PrintTable(DatabaseResult)</code>
  - GetFullList (Sort As String) As ResumableSub
    Returns a list with all items batch fetched at once.
    <code Wait For (xPocketbase.Database.SelectData.Collection("dt_Task").GetFullList("-Task_Name")) Complete (DatabaseResult As PocketbaseDatabaseResult)
    xPocketbase.Database.PrintTable(DatabaseResult)</code>
  - GetList (Page As Int, PerPage As Int, Filter As String) As ResumableSub
    Returns paginated items list.
    <code>
    Wait For (xPocketbase.Database.SelectData.Collection("dt_Task").GetList(0,2,"")) Complete (DatabaseResult As PocketbaseDatabaseResult)
    xPocketbase.Database.PrintTable(DatabaseResult)</code>
  - GetOne (RecordID As String) As ResumableSub
    Returns single item by its ID.
    <code> Wait For (xPocketbase.Database.SelectData.Collection("dt_Task").GetOne("77avq8zn44ck37m")) Complete (DatabaseResult As PocketbaseDatabaseResult)
    xPocketbase.Database.PrintTable(DatabaseResult)</code>
  - Initialize (ThisPocketbase As Pocketbase)
    Initializes the object. You can add parameters to this method if needed.
  - Parameter_Expand (Expand As String) As Pocketbase_DatabaseSelect
    Only for GetCustom
    Auto expand record relations.
  - Parameter_Fields (Fields As String) As Pocketbase_DatabaseSelect
    Only for GetCustom
    Comma separated string of the fields to return in the JSON response (by default returns all fields).
    <code>CustomQuery.Parameter_Fields("Task_Name,Task_CompletedAt")</code>
  - Parameter_Filter (Filter As String) As Pocketbase_DatabaseSelect
    Only for GetCustom
    Filter the returned records.
    Single filter:
    <code>CustomQuery.Parameter_Filter("Task_Name='Task 05'")</code>
    Multiple filter:
    <code>CustomQuery.Parameter_Filter("Task_Name='Task 05' && Task_UserId='86jzh49x5k2m387'")</code>
  - Parameter_Page (Page As Int) As Pocketbase_DatabaseSelect
    Only for GetCustom
    The page (aka. offset) of the paginated list (default to 1).
    <code>CustomQuery.Parameter_Page(0)</code>
  - Parameter_PerPage (perPage As Int) As Pocketbase_DatabaseSelect
    Only for GetCustom
    Specify the max returned records per page (default to 30).
    <code>CustomQuery.Parameter_PerPage(4)</CustomQuery.Parameter_PerPage(4)>
  - Parameter_SkipTotal (skipTotal As Boolean) As Pocketbase_DatabaseSelect
    Only for GetCustom
    If it is set the total counts query will be skipped and the response fields totalItems and totalPages will have -1 value.
    This could drastically speed up the search queries when the total counters are not needed or cursor based pagination is used.
    For optimization purposes, it is set by default for the getFirstListItem() and getFullList() SDKs methods.
  - Parameter_Sort (Sort As String) As Pocketbase_DatabaseSelect
    Only for GetCustom
    Specify the records order attribute(s).
    Add - / + (default) in front of the attribute for DESC / ASC order.
    <code>CustomQuery.Parameter_Sort("-Task_Name") 'DESC</code>
Pocketbase_DatabaseUpdate
- Functions:
  - Collection (TableName As String) As Pocketbase_DatabaseUpdate
  - Execute (RecordId As String) As ResumableSub
  - Initialize (ThisPocketbase As Pocketbase)
    Initializes the object. You can add parameters to this method if needed.
  - Parameter_Expand (Expand As String) As Pocketbase_DatabaseUpdate
    Auto expand record relations.
  - Parameter_Fields (Fields As String) As Pocketbase_DatabaseUpdate
    Comma separated string of the fields to return in the JSON response (by default returns all fields).
    <code>CustomQuery.Parameter_Fields("Task_Name,Task_CompletedAt")</code>
  - Parameter_Files (Files As List)
  - Update (ColumnValue As Map) As Pocketbase_DatabaseUpdate
Pocketbase_Functions
- Functions:
  - BytesToImage (bytes As Byte) As B4XBitmap
  - ConvertFile2Binary (Dir As String, FileName As String) As Byte()
  - CreateMultipartFileData (Dir As String, FileName As String, KeyName As String, ContentType As String) As MultipartFileData
    If you leave ContentType empty then the content type itself is determined using the file extension
  - GetFileExt (FileName As String) As String
  - GetFilename (fullpath As String) As String
  - GetISO8601UTC (Ticks As Long) As String
    ISO8601UTC
  - GetMimeTypeByExtension (Extension As String) As String

    [B4X] Get mime type by extension

    If something is missing, I will gladly add the function. Log(GetMimeTypeByExtension("jpg")) Public Sub GetMimeTypeByExtension(Extension As String) As String Extension = Extension.Replace(".","").ToLowerCase Select Extension Case "jpg","png","gif","bmp","ico","svg","webp"...

    www.b4x.com
  - ParseDateTime (DateString As String) As Long
Pocketbase_InternFunctions
- Functions:
  - CreateDatabaseResult (JsonString As String) As PocketbaseDatabaseResult
  - GenerateResult (j As HttpJob) As Map
  - GetJWTPayload (Token As String) As Map
  - PatchMultipart (j As HttpJob, Link As String, NameValues As Map, Files As List)
  - SubExists2 (Target As Object, TargetSub As String, NumbersOfParameters As Int) As Boolean
- Properties:
  - ErrorCode As Int
    code: 400
  - ErrorMap As Map
    reason: invalid
    domain: global
    message: EMAIL_NOT_FOUND
  - ErrorMessage As String
    message: EMAIL_NOT_FOUND
Pocketbase_Storage
- Fields:
  - Tag As Object
- Functions:
  - DownloadFile (CollectionName As String, RecordId As String, FileName As String) As ResumableSub
    <code>
    Wait For (xPocketbase.Storage.DownloadFile("dt_Task","s64f723suu7b1p4","test_76uuo6rx0u.jpg")) Complete (StorageFile As PocketbaseStorageFile)
    If StorageFile.Error.Success Then
    Log($"File ${"test.jpg"} successfully downloaded "$)
    ImageView1.SetBitmap(xPocketbase.Storage.BytesToImage(StorageFile.FileBody))
    Else
    Log("Error: " & StorageFile.Error.ErrorMessage)
    End If
    </code>
  - Initialize (ThisPocketbase As Pocketbase)
    Initializes the object. You can add parameters to this method if needed.
  - Parameter_Thumb (Thumb As String) As Pocketbase_Storage
    If your file field has the Thumb sizes option, you can get a thumb of the image file (currently limited to jpg, png, and partially gif – its first frame)
    The following thumb formats are currently supported:
    WxH (e.g. 100x300) - crop To WxH viewbox (from center)
    WxHt (e.g. 100x300t) - crop To WxH viewbox (from top)
    WxHb (e.g. 100x300b) - crop To WxH viewbox (from bottom)
    WxHf (e.g. 100x300f) - fit inside a WxH viewbox (without cropping)
    0xH (e.g. 0x300) - resize To H height preserving the aspect ratio
    Wx0 (e.g. 100x0) - resize To W width preserving the aspect ratio
    <code>
    Dim GetFile As Pocketbase_Storage = xPocketbase.Storage
    GetFile.Parameter_Thumb("100x300")
    Wait For (GetFile.DownloadFile("dt_Task","s64f723suu7b1p4","test_76uuo6rx0u.jpg")) Complete (StorageFile As PocketbaseStorageFile)
    </code>
  - UploadFile (CollectionName As String, RecordId As String, FileData As MultipartFileData) As ResumableSub
    Single file upload
    <code>
    Dim FileData As MultipartFileData
    FileData.Initialize
    FileData.Dir = File.DirAssets
    FileData.FileName = "test.jpg"
    FileData.KeyName = "Task_Image"
    FileData.ContentType = "image/png"
    Wait For (xPocketbase.Storage.UploadFile("dt_Task","s64f723suu7b1p4",FileData)) Complete (DatabaseResult As PocketbaseDatabaseResult)
    xPocketbase.Database.PrintTable(DatabaseResult)
    </code>
  - UploadFiles (CollectionName As String, RecordId As String, FileData As List) As ResumableSub
    If your file field supports uploading multiple files
    FileDate - List of MultipartFileData
    <code>
    Dim lst_Files As List : lst_Files.Initialize
    lst_Files.Add(Pocketbase_Functions.CreateMultipartFileData(File.DirAssets,"test.jpg","Task_Image",""))
    lst_Files.Add(Pocketbase_Functions.CreateMultipartFileData(File.DirAssets,"test2.jpg","Task_Image",""))
    Wait For (xPocketbase.Storage.UploadFiles("dt_Task","s64f723suu7b1p4",lst_Files)) Complete (DatabaseResult As PocketbaseDatabaseResult)
    xPocketbase.Database.PrintTable(DatabaseResult)
    </code>

Setup
1. Follow the Introductions docs

B4X:

Public xPocketbase As Pocketbase
#If B4J
xPocketbase.Initialize("http://127.0.0.1:8090") 'Localhost -> B4J only
#Else
xPocketbase.Initialize("http://192.168.188.142:8090") 'IP of your PC
#End If
xPocketbase.InitializeEvents(Me,"Pocketbase")
xPocketbase.LogEvents = True

Changelog

1.00
- Release

Have Fun

Please always create a new thread for questions and problems, thank you

Last edited: Wednesday at 8:55 PM

Click to expand...

B4A Library [B4X] PocketBase - Open Source backend in 1 file

PocketBase - Open Source backend in 1 file

GitHub - StolteX/B4X-PocketBase

[B4X] Get mime type by extension

Attachments

Mashiane

Expert

Alexander Stolte

Expert

Similar Threads
