B4A Library display.io ads service



1. Register with http://www.display.io/en/, create a new app and an interstitial ad unit.
2. Download their sdk and copy it to the additional libraries folder.
3. Add to manifest editor:
B4X:
AddPermission(android.permission.INTERNET)
AddPermission(android.permission.ACCESS_NETWORK_STATE)
AddPermission(android.permission.ACCESS_WIFI_STATE)
AddApplicationText(
<activity android:name="io.display.sdk.DioActivity"
   android:configChanges="orientation|screenSize|keyboardHidden"/>
<activity android:name="io.display.sdk.DioTranslucentActivity"
   android:configChanges="orientation|screenSize|keyboardHidden"
   android:theme="@android:style/Theme.Translucent.NoTitleBar" />
<activity android:name="io.display.sdk.device.PermissionsHandler" />
)
4. Dependencies:
B4X:
#AdditionalJar: com.android.support:appcompat-v7
#AdditionalJar: com.android.support:support-v4
#AdditionalJar: com.android.support:percent
#AdditionalJar: io.display.sdk-1.5.0
Note that the sdk version might be different. It is part of the jar file name.

5. Code:
B4X:
Sub Process_Globals

End Sub

Sub Globals
   Private DisplayIOController As JavaObject
   Private ctxt As JavaObject
End Sub

Sub Activity_Create(FirstTime As Boolean)
   InitDisplayIO("1215")
End Sub

Sub InitDisplayIO (AppId As String)
   ctxt.InitializeContext
   DisplayIOController = DisplayIOController.InitializeStatic("io.display.sdk.Controller").RunMethodJO("getInstance", Null)
   DisplayIOController.RunMethod("init", Array(ctxt, AppId))
End Sub

Sub ShowInterstitial (UnitId As String)
   Dim res As Boolean = DisplayIOController.RunMethod("showAd", Array(ctxt, UnitId))
   Log(res)
End Sub

Sub Activity_Click
   ShowInterstitial("1848")
End Sub

Make sure to update the AppId and UnitId.

Depends on JavaObject.

Update:

- A developer who used display.io in the past has contacted me and said that based on his experience he suspects that display.io ads do not comply with Google policies and can cause your app to be suspended.
- It is important to note that Anywhere Software is not affiliated with any ad service and we don't endorse any third party service.
- I'm just providing the simple code that allows to directly access their SDK.
- I hope that a representative from display.io will be able to clarify it.

Last edited:

sorex

Expert
Licensed User
Longtime User
Thanks.

Is this the direct wrapless method to use their sdk?

There were B4A libraries before but all of them had their issues and made by different people for them.

Reporting the issues lead to a dead end of promises so using the sdk that works right is always a plus.


Douglas Farias

Expert
Licensed User
Longtime User
Hi.

Please, can you or someone with knowledge in libs update this example? Currently it is no longer working, I believe the io display has had some updates.

I noticed that there were some changes in SKD and even some added listeners.

SDK

ARR download (4.4.1 the last)

Java sample app

I tried to download the latest .arr from the sdk and unfortunately the example does not compile, it displays the following error.
C:\android\tools\..\extras\b4a_local\unpacked-io.display.sdk-4.4.1-63729591276479\res\layout\ad_item_layout.xml:20: error: No resource identifier found for attribute 'layout_constraintBottom_toBottomOf' in package 'teste.app.iddouglasdisplay'
C:\android\tools\..\extras\b4a_local\unpacked-io.display.sdk-4.4.1-63729591276479\res\layout\ad_item_layout.xml:20: error: No resource identifier found for attribute 'layout_constraintStart_toStartOf' in package 'teste.app.iddouglasdisplay'
C:\android\tools\..\extras\b4a_local\unpacked-io.display.sdk-4.4.1-63729591276479\res\layout\ad_item_layout.xml:30: error: No resource identifier found for attribute 'layout_constraintBottom_toBottomOf' in package 'teste.app.iddouglasdisplay'
C:\android\tools\..\extras\b4a_local\unpacked-io.display.sdk-4.4.1-63729591276479\res\layout\ad_item_layout.xml:30: error: No resource identifier found for attribute 'layout_constraintEnd_toEndOf' in package 'teste.app.iddouglasdisplay'
C:\android\tools\..\extras\b4a_local\unpacked-io.display.sdk-4.4.1-63729591276479\res\layout\ad_item_layout.xml:48: error: No resource identifier found for attribute 'layout_constraintEnd_toEndOf' in package 'teste.app.iddouglasdisplay'
C:\android\tools\..\extras\b4a_local\unpacked-io.display.sdk-4.4.1-63729591276479\res\layout\ad_item_layout.xml:48: error: No resource identifier found for attribute 'layout_constraintTop_toTopOf' in package 'teste.app.iddouglasdisplay'
C:\android\tools\..\extras\b4a_local\unpacked-io.display.sdk-4.4.1-63729591276479\res\layout\ad_item_layout.xml:61: error: No resource identifier found for attribute 'layout_constraintBottom_toBottomOf' in package 'teste.app.iddouglasdisplay'
C:\android\tools\..\extras\b4a_local\unpacked-io.display.sdk-4.4.1-63729591276479\res\layout\ad_item_layout.xml:61: error: No resource identifier found for attribute 'layout_constraintEnd_toEndOf' in package 'teste.app.iddouglasdisplay'
C:\android\tools\..\extras\b4a_local\unpacked-io.display.sdk-4.4.1-63729591276479\res\layout\ad_item_layout.xml:81: error: No resource identifier found for attribute 'layout_constraintBottom_toBottomOf' in package 'teste.app.iddouglasdisplay'
C:\android\tools\..\extras\b4a_local\unpacked-io.display.sdk-4.4.1-63729591276479\res\layout\ad_item_layout.xml:81: error: No resource identifier found for attribute 'layout_constraintEnd_toEndOf' in package 'teste.app.iddouglasdisplay'
C:\android\tools\..\extras\b4a_local\unpacked-io.display.sdk-4.4.1-63729591276479\res\layout\ad_item_layout.xml:81: error: No resource identifier found for attribute 'layout_constraintStart_toStartOf' in package 'teste.app.iddouglasdisplay'

Thank you!
I'm here if you need help with testing.

Last edited:

Douglas Farias

Expert
Licensed User
Longtime User
Hello everyone.
Complementing the Erel example, below is an example using the latest SDK version (4.4.5) and also using banner.

Download the 4.4.5 arr file.
B4X:
#AdditionalJar: sdk-4.4.5.aar
#AdditionalJar: com.android.support.constraint:constraint-layout

Manifest
XML:
'DISPLAY IO
AddPermission(android.permission.INTERNET)
AddPermission(android.permission.ACCESS_NETWORK_STATE)
AddPermission(android.permission.ACCESS_WIFI_STATE)
AddPermission(android.permission.ACCESS_FINE_LOCATION)
AddPermission(android.permission.ACCESS_COARSE_LOCATION)
AddApplicationText(
<activity android:name="com.brandio.ads.DioActivity"
   android:configChanges="orientation|screenSize|keyboardHidden"/>
<activity android:name="com.brandio.ads.DioTranslucentActivity"
   android:configChanges="orientation|screenSize|keyboardHidden"
   android:theme="@android:style/Theme.Translucent.NoTitleBar" />
<activity android:name="com.brandio.ads.device.PermissionsHandler" />
)
Service
B4X:
#Region  Service Attributes
    #StartAtBoot: False
#End Region

Sub Process_Globals

    'GENERAL
    Private appId As String = "xxxx"
    Private controllerDisplayio As JavaObject
    Private ctxt As JavaObject
    Private SdkListener As Object
    Private retryTime As Int = 30000
    Private reloadTime As Int = 2000

    'INTER
    Private intersticialAd As JavaObject
    Private intersticialPlacementId As String = "xxxx"
    Private intersticialPlacement As JavaObject
    Public isInterstitialReady As Boolean = False

    'BANNER
    Public bannerView As JavaObject
    Private bannerPlacementId As String = "xxxx"
    Private bannerPlacement As JavaObject
    Private AdRequestBanner As JavaObject
    Public isBannerReady As Boolean = False

End Sub

Sub Service_Create

    'INITIALIZE CONTEXT
    ctxt.InitializeContext

    'INITIALIZE SDK
    controllerDisplayio = controllerDisplayio.InitializeStatic("com.brandio.ads.Controller").RunMethod("getInstance", Null)
    SdkListener = controllerDisplayio.CreateEventFromUI("com.brandio.ads.listeners.SdkInitListener", "SDK", Null)
    controllerDisplayio.RunMethod("init", Array(ctxt, Null, appId, SdkListener))

End Sub

Sub Service_Start (StartingIntent As Intent)
    Service.StopAutomaticForeground
End Sub

Sub Service_Destroy

End Sub


Sub SDK_Event (MethodName As String, Args() As Object) As Object
    Select MethodName

        Case "onInit"
            LogColor("onInit SDK Displayio", Colors.Yellow)
            intersticialPlacement = controllerDisplayio.RunMethod("getPlacement", Array(intersticialPlacementId))
            bannerPlacement = controllerDisplayio.RunMethod("getPlacement", Array(bannerPlacementId))
            Get_Inter
            Get_Banner

        Case "onInitError"
            LogColor("onInitError SDK Displayio", Colors.Yellow)

    End Select
    Return Null
End Sub





#Region INTER

Sub Get_Inter

    Private AdRequest As JavaObject = intersticialPlacement.RunMethod("newAdRequest", Null)
    Dim AdRequestListener As Object = AdRequest.CreateEventFromUI("com.brandio.ads.listeners.AdRequestListener", "adRequestIntersticial", Null)
    AdRequest.RunMethod("setAdRequestListener", Array(AdRequestListener))
    AdRequest.RunMethod("requestAd", Null)

End Sub


Sub adRequestIntersticial_Event (MethodName As String, Args() As Object) As Object
    Select MethodName

        Case "onAdReceived"
            LogColor("onAdReceived Inter Displayio", Colors.Yellow)
            Private AdProvider As JavaObject = Args(0)
            Dim AdLoadListener As Object = AdProvider.CreateEventFromUI("com.brandio.ads.listeners.AdLoadListener", "adLoadIntersticial", Null)
            AdProvider.RunMethod("setAdLoadListener", Array(AdLoadListener))

            Try
                AdProvider.RunMethod("loadAd", Null)
            Catch
                If LastException.IsInitialized Then Log(LastException)
                Retry_Inter
            End Try


        Case "onNoAds"
            LogColor("onNoAds Inter Displayio", Colors.Yellow)
            isInterstitialReady = False
            Retry_Inter

    End Select
    Return Null
End Sub


Sub adLoadIntersticial_Event (MethodName As String, Args() As Object) As Object
    Select MethodName

        Case "onLoaded"
            LogColor("onLoaded Inter Displayio", Colors.Yellow)
            intersticialAd = Args(0)
            Dim AdEventListener As Object = intersticialAd.CreateEventFromUI("com.brandio.ads.listeners.AdEventListener", "AdEventIntersticial", Null)
            intersticialAd.RunMethod("setEventListener", Array(AdEventListener))
            isInterstitialReady = True


        Case "onFailedToLoad"
            LogColor("onFailedToLoad Inter Displayio", Colors.Yellow)
            isInterstitialReady = False
            Retry_Inter

    End Select
    Return Null
End Sub


Sub AdEventIntersticial_Event (MethodName As String, Args() As Object) As Object
    Select MethodName

    Case "onShown"
        LogColor("onShown Inter Displayio", Colors.Yellow)
        isInterstitialReady = False

    Case "onFailedToShow"
        LogColor("onFailedToShow Inter Displayio", Colors.Yellow)
        isInterstitialReady = False
        Reload_Inter

    Case "onClicked"
        LogColor("onClicked Inter Displayio", Colors.Yellow)
        isInterstitialReady = False

    Case "onClosed"
        LogColor("onClosed Inter Displayio", Colors.Yellow)
        isInterstitialReady = False
        Reload_Inter

    Case "onAdCompleted"
        isInterstitialReady = False
        LogColor("onAdCompleted Inter Displayio", Colors.Yellow)

    End Select
    Return Null
End Sub

Sub Retry_Inter
    isInterstitialReady = False
    Sleep(retryTime)
    Get_Inter
End Sub

Sub Reload_Inter
    isInterstitialReady = False
    Sleep(reloadTime)
    Get_Inter
End Sub

Sub Show_Inter
    intersticialAd.RunMethod("showAd", Array(ctxt))
End Sub

#End Region






#Region BANNER

Sub Get_Banner

    AdRequestBanner = bannerPlacement.RunMethod("newAdRequest", Null)
    Dim AdRequestListener As Object = AdRequestBanner.CreateEventFromUI("com.brandio.ads.listeners.AdRequestListener", "adRequestBanner", Null)
    AdRequestBanner.RunMethod("setAdRequestListener", Array(AdRequestListener))
    AdRequestBanner.RunMethod("requestAd", Null)

End Sub


Sub adRequestBanner_Event (MethodName As String, Args() As Object) As Object
    Select MethodName

        Case "onAdReceived"
            LogColor("onAdReceived Banner Displayio", Colors.Yellow)
            Private AdProvider As JavaObject = Args(0)
            Dim AdLoadListener As Object = AdProvider.CreateEventFromUI("com.brandio.ads.listeners.AdLoadListener", "adLoadBanner", Null)
            AdProvider.RunMethod("setAdLoadListener", Array(AdLoadListener))

            Try
                AdProvider.RunMethod("loadAd", Null)
            Catch
                If LastException.IsInitialized Then Log(LastException)
                Retry_Banner
            End Try


        Case "onNoAds"
            LogColor("onNoAds Banner Displayio", Colors.Yellow)
            isBannerReady = False
            Retry_Banner

    End Select
    Return Null
End Sub


Sub adLoadBanner_Event (MethodName As String, Args() As Object) As Object
    Select MethodName

        Case "onLoaded"
            LogColor("onLoaded Banner Displayio", Colors.Yellow)
            bannerView = bannerPlacement.RunMethod("getBanner", Array(ctxt, AdRequestBanner.RunMethod("getId", Null)))
            isBannerReady = True


        Case "onFailedToLoad"
            LogColor("onFailedToLoad Banner Displayio", Colors.Yellow)
            isBannerReady = False
            Retry_Banner

    End Select
    Return Null
End Sub


Sub Retry_Banner
    isBannerReady = False
    Sleep(retryTime)
    Get_Banner
End Sub

#End Region
I use it in a service (where all events work correctly), but you can compile it as a library or use it as a class.

Interstitial
B4X:
If Not(IsPaused(displayio)) And displayio.isInterstitialReady Then CallSub(displayio, "Show_Inter")

Banner
B4X:
If Not(IsPaused(displayio)) And displayio.isBannerReady Then
    Private bannerView As View
    bannerView = displayio.bannerView
    Activity.AddView(bannerView,0%x, 100%y - 51dip, 100%x, 51dip)
End if


Thx
