B4A Library [B4X] AS Badges

I took the original Badger code from @Erel and modified it to create a new view.

I spend a lot of time in creating views, some views i need by my self, but some views not and to create a high quality view cost a lot of time. If you want to support me, then you can do it here by Paypal or with a coffee.

TextAnimation_Slide

TextAnimation_Growth

TextAnimation_FadeIn

Dim BadgeProperties As AS_Badges_BadgeProperties = AS_Badges1.BadgeProperties
BadgeProperties.BackgroundColor = xui.Color_Red
BadgeProperties.Orientation = AS_Badges1.Orientation_TopLeft
AS_Badges1.SetBadge2(xlbl_Label,8,BadgeProperties)

ASBadges
Author: Alexander Stolte
Version: 1.01

• AS_Badges
  • Functions:
    • Class_Globals As String
    • CreateAS_Badges_BadgeProperties (BackgroundColor As Int, TextColor As Int, xFont As B4XFont, Orientation As String) As AS_Badges_BadgeProperties
    • GetBadgeCounter (view As B4XView) As Int
      Gets the Count of the badge on this view
    • getBadgeProperties As AS_Badges_BadgeProperties
    • getFadeInDuration As Long
      Default: 250
    • getOrientation_BottomLeft As String
    • getOrientation_BottomRight As String
    • getOrientation_TopLeft As String
    • getOrientation_TopRight As String
    • getRadius As Float
    • getTextAnimation As String
    • getTextAnimation_FadeIn As String
    • getTextAnimation_Growth As String
    • getTextAnimation_Slide As String
    • getTextDuration As Long
      Default: 250
    • Initialize As String
    • IsInitialized As Boolean
      Tests whether the object has been initialized.
    • SetBadge (View As B4XView, Badge As Int) As String
    • SetBadge2 (View As B4XView, Badge As Int, Properties As AS_Badges_BadgeProperties) As String
    • setBadgeProperties (Properties As AS_Badges_BadgeProperties) As String
    • setFadeInDuration (Duration As Long) As String
    • setRadius (Radius As Float) As String
    • setTextAnimation (AnimationName As String) As String
    • setTextDuration (Duration As Long) As String
  • Properties:
    • BadgeProperties As AS_Badges_BadgeProperties
    • FadeInDuration As Long
      Default: 250
    • Orientation_BottomLeft As String [read only]
    • Orientation_BottomRight As String [read only]
    • Orientation_TopLeft As String [read only]
    • Orientation_TopRight As String [read only]
    • Radius As Float
    • TextAnimation As String
    • TextAnimation_FadeIn As String [read only]
    • TextAnimation_Growth As String [read only]
    • TextAnimation_Slide As String [read only]
    • TextDuration As Long
      Default: 250
• AS_Badges_BadgeProperties
  • Fields:
    • BackgroundColor As Int
    • IsInitialized As Boolean
      Tests whether the object has been initialized.
    • Orientation As String
    • TextColor As Int
    • xFont As B4XFont
  • Functions:
    • Initialize
      Initializes the fields to their default value.

Changelog

• 1.00
  • Release
• 1.01 (read more)
  • B4J BugFix - The text animation now no longer slips outside the badge
  • Add get and set TextAnimation - Various text change animations
    • Default: TextAnimation_Slide
    • TextAnimation_Slide - The old text slides out to the right
    • TextAnimation_Growth - The font grows animated
    • TextAnimation_FadeIn - The alpha of the new text is increased animatedly
• 1.02 (read more)
  • Breaking Change - Initialize needs now a CallBack and a EventName
  • Add Event Click
• 1.03 (read more)
  • BugFixes
  • Add set AutoRemove - Removes the badge if the value is 0
    • Default: True
• 1.04
  • Property descriptions added
  • Add get and set xGap and yGap - This allows you to change the position of the badge. e.g. position it further to the left or higher up so that it matches the design.
    • Default: 0

Have Fun



[yiankos1]

Once again, great job Alex!!!



[Rubsanpe]

You really do a fantastic job. Donation sent for your great work.

Rubén



[Alexander Stolte]

Thank you both



[Alexander Stolte]

Update

• 1.01
  • B4J BugFix - The text animation now no longer slips outside the badge
  • Add get and set TextAnimation - Various text change animations
    • Default: TextAnimation_Slide
    • TextAnimation_Slide - The old text slides out to the right
    • TextAnimation_Growth - The font grows animated
    • TextAnimation_FadeIn - The alpha of the new text is increased animatedly

TextAnimation_Slide

TextAnimation_Growth

TextAnimation_FadeIn



[Alexander Stolte]

Update

• 1.02
  • Breaking Change - Initialize needs now a CallBack and a EventName
  • Add Event Click

Initialize needs now a CallBack and a EventName

AS_Badges1.Initialize(Me,"Badges1")

Click Event
You can do something like this

Private Sub Badges1_Click (Parent As B4XView)
    AS_Badges1.SetBadge(Parent,AS_Badges1.GetBadgeCounter(Parent) +1)
End Sub



[jbaillie2461]

Quick Question how do you hide the Badget when the click de selects something from the cart



[jbaillie2461]

badget is 1 know user take item out of cart and want to set it to zero cant do



[jbaillie2461]

Or hide the badge



[mcqueccu]

Or hide the badge

Start a new Thread and form your question well



[Alexander Stolte]

Quick Question how do you hide the Badget when the click de selects something from the cart

Set the value to 0

if you need more help, please start a new thread with more infos.



[jbaillie2461]

I found the issue I was re intilizing the badge each time instead of setting it thank for the reply lovely compnent



[Alexander Stolte]

Update

• 1.03
  • BugFixes
  • Add set AutoRemove - Removes the badge if the value is 0
    • Default: True

AS_Badges1.AutoRemove = False
AS_Badges1.SetBadge(xlbl_Label,0)



[Alexander Stolte]

Update

• 1.04
  • Property descriptions added
  • Add get and set xGap and yGap - This allows you to change the position of the badge. e.g. position it further to the left or higher up so that it matches the design.
    • Default: 0
